Eco water level recorder (4m) - U20L-04
Write your review
The HOBO U20L-04 is one data recorder affordable high quality designed for continuous measurement of level and temperature water with a accuracy 0.1% for use in freshwater and salt up to one depth of 4m.
He owns a design not ventilated for one practical deployment and is compatible with HOBOware software for precise conversion taking into account the barometric pressure, the temperature and water density.
This data recorder is suitable for outdoor environments and aquatic, including well streams, lakes wetlands and areas tide.
Important:
Requires configuration and unloading of data :
- Software HOBOware Pro
- The optical USB base station Base-U-4
€385.00
Guaranteed security for your online purchases Your purchases are protected by SSL encryption, guaranteeing maximum privacy and security.
Fast and reliable delivery We offer fast and secure delivery options, followed to your door.
Easy Returns Policy Return your products easily within 30 days, fast refund guaranteed.
THE' data recorder de water level HOBO U20L-04 is a solution of measurement and ongoing monitoring low cost quality standards level and the water temperature in a wide range ofaquatic environments and until 4m depth.
It presents a accuracy of 0.1%, one polypropylene housing for use in freshwater and salt, and one design not ventilated for one practical deployment and hassle-free.
This data recorder requires either the U-DTW-1 waterproof shuttle or the optical USB base station Base-U-4 for configuration and unloading of data and software HOBOware Pro.
Technical specifications:
- Autonomous and unventilated design allows easy deployment
- Ideal for use in freshwater and salt water environments, including wells, streams, lakes, wetlands and tidal areas
- Depths up to 13, 30 or 100 feet depending on the model
- Durable ceramic pressure sensor resistant to frost
- Software HOBOware Pro allows easy conversion to accurate water level reading, fully compensated for barometric pressure, temperature and water density.
Note: A calibration certificate is not proposed for this recorder .
If you need a NIST traceable calibration certificate, please consult the U20-001-04 (fresh water) or U20-001-04-Ti (salt water).
Functionality of the (absolute) and water level sensor:
- Operating range: 0 to 207 kPa (0 to 30 psia), approximately 0 to 9 m (0 to 30 ft) water depth at sea level, or 0 to 12 m (0 to 40 ft) water at 3,000 m (10 000 ft) altitude
- Calibrated factory range: 69 to 207 kPa, 0° to 40°C (10 to 30 psia, 32 to 104°F)
- Breaking pressure: 310 kPa or 18 m deep (45 psia or 60 feet)
- Water level accuracy*:
Typical error: ±0.1 % FS, 1.0 cm (0.03 ft) water
Maximum error: ±0.2% FS, 2.0 cm (0.06 ft) water
- Gross pressure accuracy**: ±0.3% FS, maximum error of 0.62 kPa (0.09 psi)
- Resolution: - Pressure response time (90%)***:
Temperature sensor features:
- Temperature range: -20° to 50°C (-4° to 122°F)
- Accuracy: ±0.44°C from 0° to 50°C (±0.79°F from 32° to 122°F), see manual for route
- Resolution: 0.10°C to 25°C (0.18°F to 77°F), see manual for the route
- Response time (90%): 10 minutes in water (typical)
- Stability (driving): 0.1°C (0.18°F) per year
Recorder Features:
- Real time clock: ±1 minute per month 0° to 50°C (32° to 122°F)
- Battery: 2/3 AA, 3.6 V lithium, factory replaceable
- Battery autonomy (typical use): 5 years with a recording interval of at least 1 minute
- Memory (non-volatile): memory of 64 Kb (approximately 21,700 pressure and temperature samples)
- Weight:
Approximately 154 g (5.43 oz) in air
Approximately 53.9 g (1.9 oz) in freshwater
- Dimensions: 3.18 cm (1.25 inches) in diameter, 15.24 cm (6.0 inches) in length; 6.3 mm (0.25 inches) diameter mounting hole
- Wet materials: Polypropylene case and cord, Viton and Buna-N O-rings, ceramic sensor in an acetal tip, stainless steel screws suitable for salt water
- Journalization interval:
Fixed or multiple rate logging intervals, with up to 8 intervals and user-defined logging times
Recording intervals from 1 second to 6 p.m.
Please refer to the HOBOware User Guide for more details.
- Launch modes: immediate start and delayed start
- Method of unloading: Unload during logging, stop and unload
- Battery indicator: battery voltage can be viewed on the status screen and possibly stored in a data file, low battery indication in the data file.
- Environmental assessment: IP68
