Current sensor 100A T-ACT-0750-100

100A current sensor T-ACT-0750-100 offers accuracy to the extent of electric current, ensuring reliable and accurate results.
It is ideal for applications where accurate measurement of current is crucial for security and performance electrical system.
With a unique opening and closing mechanism, the split core power transformer can be used with one hand, making it easier to use, even under demanding working conditions or restricted spaces.
THE'20 mm window opening (0.78 inches) makes it easy to pass the driver through the transformer, eliminating the need to cut or disconnect the cable, which considerably reduces interruptions in normal operations.
The transformer is equipped with an integrated load strength and offers a 333 mVac voltage outlet with nominal full-scale current, ensuring safe and reliable operation of the device.
Without the need for a short circuit block, this transformer is compatible with the use of safety gloves, which reinforces security during installation and handling.
The sensor is versatile and is perfectly suitable for industrial electrical installations, to energy monitoring systems, to energy audits, as well as any other applications requiring precise measurement of electrical current.

Important:

See the product pages of the'data recorder to ensure that you have the appropriate interfaces (modules, adapter, etc.) to deploy this sensor.

Technical specifications:

- unprecedented linearity
- Window opening 20 mm (0.78 inches)
- The Accu-CT split core power transformer offers exceptional linearity and phase angle precision with a unique one-hand opening and closing mechanism
- Safe: integrated load strength, 333 mV AC voltage output at nominal full-scale current, no short-circuit block required
- IEEE C57.13 and IEC 60044-1 accuracy: over the entire temperature range and up to 1% of rated current
- Exceptionally low phase angle error: essential for accurate power and energy measurements
- Compatible with gloves: easy to open and install with one hand while wearing safety gloves
- Approvals: UL recognized, CE marking, RoHS

Sensor Features:

- Accuracy: ±0.75% from 1% to 120% of nominal primary current
- Phase angle: ±0.5 degrees (30 minutes) from 1% to 120% of rated current
- Precision standards: IEEE C57.13 class 1.2 and IEC 60044-1 class 1.0
- Primary nominal value: 5 to 250 A, 600 Vca, 60 Hz nominal
- Output: 333.33 mVca at nominal current
- Operating temperature: -30°C to 55°C
- Sure: integrated load strength, no short-circuit block required, unless otherwise specified
- Standard cable length: 8 ft (2.4 m), 20 AWG
- Recognized UL, CE marking, RoHS
- Assembled in the United States: qualified according to the Buy American provision in the 2009 ARRA
- Dimensions:
Width : 2.38 inches
Height : 2.40 inches
Thickness : 0.90 inches
Fenêtre : 0.78 inches
