The weather station HOBO U30-NRC is a solution monitoring of the'external environment sustainable and easily configurable for specific applications which may collect until 15 channels de environmental data.
It works in environments domestic and external and includes robust housing plug-and-play sensors, one configurable relays and one uSB communication for quick data download.
Important:
External sensors sold separately.
Requires software HOBOware and a communications device.
See less associated articles below.
Guaranteed security for your online purchases Your purchases are protected by SSL encryption, guaranteeing maximum privacy and security.
Fast and reliable delivery We offer fast and secure delivery options, followed to your door.
Easy Returns Policy Return your products easily within 30 days, fast refund guaranteed.
One weather station robust for monitoring of the'external environment.
Easy configurable for specific application needs, with up to 15 channels to collect environmental data, then download them to the software HOBOware for analysis.
Software HOBOware Pro is recommended for extended features.
Technical characteristics of the station:
- All electronic components are housed in a robust double weather resistant and inviolable housing
- The configuration is fast and easy thanks to plug-and-play sensors
- Quickly unloading data via USB
- Optional analog inputs with sensor excitement
- Includes a relay that can be activated on user-defined alarm conditions
Station Features:
- Normal operating range: -20 to 40°C (-4 to 104°F)
- Extended operating range -40 to 60°C (-40 to 140°F)
See "Rechargeable battery life" for the impact of operations in the extended operating range.
- Smart sensor connectors: 10
- Smart sensor compatibility: compatible with most smart sensors Onset, except S-BPA, S-TMA and S-THA
- Smart sensor data channels: Maximum of 15 (some sensors use more than one data channel, see sensor manual for more details)
- Alarm output relay:
a relay contact closure can be configured as normally open, normally closed or pulsed.
Voltage: 30 V
Current: 1 A max.
- Smart sensor network cable length: up to 100 metres (328 ft)
- Recording interval: 1 second at 6 p.m
- Start modes: immediate start, at intervals, by push button or delay
- Memory modes: stop when full or wrap when full
- Memory: storage of 512 KB non-volatile flash data
- Operational indicators: 3 state lights provide basic diagnostics
- Accuracy of the time: 0 to 2 seconds for the first data point and ±5 seconds per week at 25°C (77°F)
- Type of battery/power source: 4 volts, 10 AHr, rechargeable sealed lead acid, external power supply required using one of these options: AC-U30 or solar panel (SOLAR-xW)
- Life of rechargeable battery: typically 3 to 5 years depending on the conditions of use.
Operating in the extended operating range (but outside the normal range) will reduce battery life.
- Type of communication: Full speed USB via mini-B USB connector
- Full memory download time: 4 minutes
- Access to the housing: swing door secured by two locks with eyelets for securing with locks not provided
- Materials:
External housing : Polycarbonate/PBT mixture with stainless steel hinge axes and brass inserts
Interior housing : Polycarbonate with brass inserts
Balls in U : steel with zinc bichromate finish
Joints : Silicon rubber
Cable entrance channel : EPDM rubber
Cable entry bars : Aluminium, metal ear screws with plastic heads
- Dimensions: 18.9 H x 11.8 D x 18.1 L cm
- Weight: 2.2 kg (4 pounds 13 ounces)
- Assembly:
3.8 cm mast or wall support
1.5-inch mast or wall support
- Environmental assessment: weather resistant housing, tested according to NEMA 6 (requires correct installation of cable channel system)
Contents of the box:
- HOBO U30-NRC station data recorder
- Ready-to-mount
- Earthing wire
- Cable pass and sealing kit
- Optional analog sensor port (if ordered)
- Optional sensor extension card (if ordered)
